DAKO KNL5-63 1P+N 63A Residual current circuit breaker (RCCB)
600 บาท
รหัสสินค้า:IDAK31-KNL563632
หมวดหมู่/แบรนด์:Residual Current Circuit Breaker (RCCB)DAKO
| Model | KNL5-63 |
| Poles | 1P+N |
| Rated working current | 63A |
| Rated working voltage | 240V |
| Rated making and breaking capacity | In ≤ 63A 630A |
| Limiting value of un-operating current | 6In |
| Making and breaking capacity (IC) | 6kA |
| Frame class | 63A |
| Rated frequency | 50Hz |
| Rated residual operating current | 30mA |
| Rated residual un-operating current | 15mA |
| Sensibility | AC Type |
| Maximum operating time | I Δ n t ≤ 0.15 |
| Limiting value of un-operating current | 6In |
| Rated limiting short-circuit current | 6kA |
